Fine Adjust Applicator for “MX150” Blade
NOTES
1. Molex recommends an extra perishable tooling kit be maintained at your facility.
2. Verify tooling alignment by manually cycling the press and Applicator before crimping under power. Check that
all screws are tight.
3. Slugs, Terminals, Dirt and Oil should be kept clear of work area.
4. Wear safety glasses at all times.
5. For recommended maintenance refer to the FineAdjust Manual.
CAUTION : This applicator should only be used in a press with a shut height of 135.80 mm (5.346”). Tooling
damage could result at a lower setting.
CAUTION : To prevent injury never operate this Applicator without the guards supplied with the press or wire-
processing machine in place. Reference the press or wire processing manufacturer’s instruction manual.
CAUTION : Molex crimp specifications are valid only when used with Molex terminals, applicators and tooling.
http://www.molex.com
Doc No: ATS-639000600
Revision: C
Release Date: 06-18-07
Revision Date: 08-15-11
UNCONTROLLED COPY
Page 6 of 6
